Vatech A9 (PHT-30CSS)
Technical manual
VDH-TeM-098
89 / 214
COPYRIGHT© 2020 VATECH.
2. Check the location of the dosimeter again through the PROJ file.
3. If the location of the dosimeter is not in the circle, re-locate the position and capture it again.
Set to X: 92, Y: 490, M: 50, and set the dosimeter position so that
the dosimeter's sensor is located in the circle.
The circle located in the third part of
the dose meter should fit inside the
blue circle.
To Next Page
