3. Before Installing the System
vatech A9 (Model: PHT-30CSS) Installation Manual 37
English
Part
No.
Items Specification Figure QTY
Comment
s
Confirmed
(OK?)
17 Base Cap White Silicon 4
Base
Option
Yes □ No □
18 Terminal Cap White Silicon 2 Yes □ No □
19 Left Blank Intentionally
20 Cable Tie 10 - Yes □ No □
21
Cable Ethernet Cable
1 Yes □ No □
Ethernet
Card
1 Yes □ No □
22 Protractor 1 - Yes □ No □
23 Wrench Bolt
M10 x 25
w/ Spring and
Flat Washer
4
Base
Option
Yes □ No □
24 Wrench Bolt M8 x 20 2
Base
Option
Yes □ No □
25
Wrench Bolt M8 x 35 4
Ceph
Option
Yes □ No □
C_E_Washer 4
Ceph
Option
Yes □ No □
26 Truss Bolt M4 x 6 13
Base
Option
Yes □ No □
27
Pan Head
Screw
M4 x 6 11 Yes □ No □
28
Ceph Cover - 1 Yes □ No □
Washer
Head
Screw
M3 x 6 2 Yes □ No □
29
Flat Head
Screw
M4 x 8 2 Yes □ No □
30
Socket Set
Screw
M10 x 15 4
Floor
Mount
Yes □ No □
