3. Before Installing the System
38 vatech A9 (Model:PHT-30CSS) Installation Manual
Part
No.
Items Specification Figure QTY
Comment
s
Confirmed
(OK?)
Option
31
Wall Plate
1 Yes □ No □
Terminal
Block 3 Pole
1 Yes □ No □
32
Wall Mount
Cap
Silicon
12 Yes □ No □
Wall Mount
Cap
Silicon
5
For USA
only
Yes □ No □
UP / DOWN
Switch Sheet
2 Yes □ No □
33
UP / DOWN
Switch
1
Optional
Yes □ No □
UP / DOWN
Switch
Holder
1 Yes □ No □
UP / DOWN
Switch
Sticker
1 Yes □ No □
Flat Head
Screw
M3 x 8 3 Yes □ No □
Millde Wall
Bracket
1 Yes □ No □
Wrench Bolt
M8 x 25
(2 Sems)
2 Yes □ No □
Nut M8 2 Yes □ No □
Wall Mount
Cap
Silicon
4 Yes □ No □
34 Wood Screw M12 x 70 2 For Wood Yes □ No □
