3. Before Installing the System
vatech A9 (Model: PHT-30CSS) Installation Manual 39
English
Part
No.
Items Specification Figure QTY
Comment
s
Confirmed
(OK?)
Anchor Bolt
5/16 x 60 w/
Spring and Flat
Washers
4
For
Concrete
Yes □ No □
Wood Screw M8 x 60
4
(USA: 8)
For Wood Yes □ No □
Spring
Washer
M8
4
(USA: 8)
For
Concrete
Yes □ No □
Flat Washer M8
4
(USA: 8)
For
Concrete
Yes □ No □
Flat Anchor
Bolt
M8 x 30
4
(USA: 8)
For
Concrete
Yes □ No □
Hex Bolt M8 x 15
4
(USA: 8)
For
Concrete
Yes □ No □
35
Wrench Bolt
M8 x 20 w/
Spring and Flat
Washers
2
For Wall
Barcket
Yes □ No □
Nut M8 2
For Wall
Barcket
Yes □ No □
Wrench Bolt
M8 x 15 w/
Spring and Flat
Washers
4
For Wall
Barcket
Yes □ No □
36
Wall Bracket - 1
For USA
only
Yes □ No □
Wall Bracket - 1
All
countries
except the
USA
Yes □ No □
