4. Installing the Equipment: Base Stand (Optional)

vatech A9 (Model: PHT-30CSS) Installation Manual 43

English

2. Put two wrench bolts into the holes (see below) and loosely tighten them with

an Allen Wrench to connect the Base Unit to the Column Unit.

Required Tool Allen Wrench 6 mm / 0.24”

Parts and

Accessory

Wrench Bolt

M8 x 20 - 2 pcs

(Part No. 24)

Put the bolts into the holes until

about 15 mm are left

outside.
