4
.
Installi
ng the Equipment: Base Stand (O
ptional)
44
vatech A9
(Model:PHT
-
30CSS
)
Installation Manual
3.
Connect the Base Unit to the Column Unit using two bolts provided. Insert the
bolts into the locations indicated in the image below
.
Hold the bas
e unit
to
keep
it
from
falling
.
4.
T
ight
en them with an
Allen Wrench to connect the Base Unit to t
he Column Unit.
Required T
ool
Alle
n Wrench
6 mm / 0.24”
53
55
