5. Installing the Equipment: Wall Mount
vatech A9 (Model: PHT-30CSS) Installation Manual 71
Combining the Equipment with the Anchor Bolts
1. Insert an Anchor Bolt into each hole on the Alignment Plate.
2. Grab the upper carrying handle and lift the equipment slowly until it stands on the
floor, as shown in the image below.
Be careful not to damage the cables before erecting the
equipment. Keep them clear of
the equipment.
