120 I
PaX-i3D Smart
12. Technical Specifications
12.1 Mechanical Specifications
❚
Image Magnification
Mode FDD (mm) FOD (mm) ODD (mm) Magnification
CT 600 428.57 171.43 1.4 CONSTANT
PANO 600 477.7 122.3 1.26 CONSTANT
CEPH 1745 1524 221 1.14 CONSTANT
■ FDD: Focal Spot to Detector Distance
■ FOD: Focal Spot to Object Distance
■ ODD: Object to Detector Distance (ODD = FDD - FOD)
■ Magnification = FDD / FOD
