7. Acquiring CEPH images
82 I
PaX-i3D Smart
7.1 Setting Exposure Parameters
Perform the following procedures to select the capture parameters for the specific patient
and capture mode. Please refer to 4.3 Console Software for the more information.
❚
Steps for Configuring Imaging Conditions





ex) SC Sensor(Xmaru2301CF) ex) OP Sensor(1210SGA)
1. Click the CEPH button.
2. Select the examination program under Ceph Examination
3. (For One-shot CEPH only) Do the selections that follow.
— FOV Size: Select the FOV size.
FOV Details Model
Large
: 12x10 (inches)
: 30.48x25.40 (cm)
Full size OP(1210SGA)
