12. Technical Specifications
124 I
PaX-i3D Smart
Item Description
Weight
without CEPH unit
Without Base 167 kg (368.2 lbs)
with Base 220 kg (485 lbs)
with CEPH unit
(scan type)
Without Base 202 kg (445.3 lbs)
with Base 255 kg (562.2 lbs)
with CEPH unit
(oneshot type)
Without Base 212 kg (467.4 lbs)
with Base 265 kg (584.2 lbs)
Total Height Max. 2336 mm (92 inch)
Vertical Column Movement Max. 700 mm (Max. 27.6 inch)
Dimension
(Length x Width
x Height)
without CEPH unit
1113 (L) x 1389(W) x 2336 (H) mm
43.8(L) x 54.7(W) x 92(H) inch
with CEPH unit
(scan type)
1882 (L) x 1400 (W) x 2336 (H) mm
74.1(L) x 55.1(W) x 92(H) inch
with CEPH unit
(oneshot type)
1882 (L) x 1400 (W) x 2336 (H) mm
74.1(L) x 55.1(W) x 92(H) inch
Type of installation Base stand / Wall mount
