3. Imaging System Overview
25 I
PaX-i3D Smart
English
No. Name Function
14 Chin Rest A place to rest the chin.
15 Temple Supports Patient head support: Use in PANO and CBCT modes.
16
X-ray Sensor
(PANO/CT)
PANO / CBCT Sensor
17 LED Lamp
Indicates the emission status while the x-ray is in
operation.
- Green: Ready
- Orange: X-ray ON
