COMPONENT IDENTIFICATION.
Legend:
1 3-position switch.
- Turned to “ ”, the machine and the unit heating elements are turned on and automatic filling with water is enabled; the
LED (2) comes on.
- Turned to “ ”, as well as the other active functions, steam boiler water heating is turned on; the LED (3) comes on.
- Turned to “ ”, as well as the other active functions, cup heating plate heating is turned on; the LED (4) comes on.
5 Steam tap.
6 Steam nozzle.
7 Hot water nozzle.
8 Boiler pressure gauge.
9 Pump pressure gauge.
10 Cup heating plate.
11 Drip tray with grille.
12 Filter holder.
13 Coffee unit.
14 Pushbutton panel.
15 Display.
