PLRF25C-1.2en Data transfer
49
To plug:
1. Remove protection cap.
2. Align the respective
markings on the plug and
socket.
3. Slide the plug carefully
into the socket until the
locking mechanism
engages.
To unplug:
1. Grasp the plug grip
between two fingers,
2. draw it carefully back to
the stop to disengage the
locking mechanism,
3. pull back a little harder
until the plug slips out of
the socket.
4. Attach the protection
cap.
