Vectronix BT PLRF25C User Manual

Options PLRF25C-1.2en
60
Fall of shot - FOS
Click the button once, then
immediately press and hold
it down.
The azimuth appears and is
updated continuously. Sight
the target with the aiming
mark.
Release the button to
measure the target.
PT1 OK followed by
DO PT2 is displayed.
Immediately press and hold
down the button again.
Sight the fall of shot.
Release the button to
measure the fall of shot.
The distance (
D) between
the target and fall of shot is
displayed.
AZI 504&AZI 504&
PT1 OKPT1 OK
DO PT2 DO PT2
D 20çD 20ç
20m
