Table D.
HP Volts Phase
Service
Factor
Cur.
Locked
Rotor
Cur.
Branch Ckt.
Protection
Wire Size for Max. Length of Run Shown
(From Service Entrance to Pump in Feet)
Nema
Codes
Fusetron
Ckt.
Brkr.
(Amps) (Amps) (Amps) (Amps) No. 14 No. 12 No. 10 No. 8 No. 6
2 208-230* 1 12.0 61.0 20 20 172 274 929 673 1048 H
2 208-230* 3 7.2 45.0 15 15 361 574 899 1410 2197 K
3 208-230* 3 10.5 62.0 15 20 255 406 635 997 1552 K
3 380-415 3 5.4 29.0 15 15 787 1250 1956 3070 --- K
5 208-230* 3 17.2 92.0 25 30 --- 240 376 590 920 J
5 380-415 3 8.8 49.0 15 15 472 750 1173 1841 2867 G
5 575 3 7.0 37.0 15 15 929 1477 2311 3627 --- K
*Figures represent maximum length in feet for 220 or 230 volt system. Use 75% of length for 208 volt system.
