Veeder-Root Red Jacket Maxxum Big-Flo Quick-Set Series User Manual

Parts Red Jacket Replacement Pump Motors
41
Red Jacket Replacement Pump Motors
Magnetic Contactor For 2, 3, And 5 HP 3-Phase Pumps
Three phase pump/motor units must have proper overload and quick trip heaters in-
stalled in the control box. Heaters must match starter manufacturer.
Table L.
Ordering
Number Model Number HP Length in. (mm) Weight lbs. (kg) Volts Phase
UMP
882-839-5 UMP-P200J1-2MB 2 32.1 (815) 116 (53) 208-230 1
882-840-5 UMP-P200J4-2MB 2 29.6 (752) 116 (53) 208-230 3
882-842-5 UMP-P300J4-2HB 3 34.3 (871) 120 (54) 208-230 3
882-211-5 UMP-P500J4-2K 5 42.5 (1080) 162 (74) 208-230 3
883-434-5 UMP-P300J17-3HB 3 37.4 (950) 125 (57) 380-415 3
886-511-5 UMP-P500J17-3K 5 47.0 (1200) 167 (76) 380-415 3
883-226-5 UMP-P500J6-2K 5 41.1 (1050) 162 (74) 575 3
UMP WITH DISCHARGE HEAD
883-460-5 UMP-P300J17-3HB W/DH 3 40.1 (1020) 380-415 3
886-454-5 UMP-P500J17-3K W/DH 5 49.7 (1270) 380-415 3
Table M.
SIEMENS (FURNAS) GENERAL ELECTRIC
HP Voltage Hz Heaters (3 Req’d.)
Control Box
(Coil V) Heaters (3 Req’d.)
Control Box
(Coil V)
2 208-230 60 036-072-1
279-231-5 (230V)
410649-004
410648-001 (120V)
410648-002 (240V)
410648-003 (575V)
3 208-230 60 036-076-1 410649-006
5 208-230 60 036-080-1 410649-008
5 575 60 036-100-1 279-230-5 (575V) 410649-009
3 380-415 50 036-070-1 279-231-5 (230V) 410649-005
5 380-415 50 036-074-1 279-231-5 (230V) 410649-007
WARNING
