Service and Repair Repairing the Check Valve Lock-down Screw And Seals

Figure 22. Pressurstat And Check Valve Lock-Down Screw Assembly

rj/051-301-24.eps

Protective cover

Adjustment screw

Pressurstat body

Spring

Plunger

Diaphragm

Lockdown screw

#8 Screw

Wiper seal

Wiper housing

O-ring

1/4 Screws w/

lockwashers

Vent line disconnected

and rotated out of the way

NOTICE
