Introduction Specifications
12
The weights and lengths listed below are approximate values and will vary due to manufac-
turing tolerances.
The optional trapper intake screen is available as a field installed accessory. Trapper options will increase the
length of the UMP by 3.3 inches (83 mm). For installation instructions, see Red Jacket installation instructions
#051-256-1. For models with floating suction adapter, add 2-3/8 inches (59 mm) and 4 pounds (1.8 kg).
Table 4. UMP Model Dimensions
Lengths Weight
UMP Model HP in. mm lb. kg
UMP75U17-3, AGUMP75U17-3 3/4 19 483 28 12.7
UMP150U17-3, AGUMP150S17-3 1-1/2 21-1/4 540 31 14.1
X4UMP150U17, X4AGUMP150S17 1-1/2 21-3/4 552 32 14.5
UMP200U17-4, AGUMP200S17-4 2 23-3/4 603 36 16.3
Table 5. Approximate Pump Shut Off Pressures
UMP Model Approximate Shut Off Pressure
AGUMP75S17-3, UMP75U17-3 29 psi (200 kPa) 0.74 SG @ 60°F (15°C)
AGUMP150S17-3, UMP150U17-3 32 psi (220 kPa) 0.74 SG @ 60°F (15°C)
X4AGUMP150S17, X4UMP150U17 39 psi (267 kPa) 0.74 SG @ 60°F (15°C)
AGUMP200U17-4, UMP200U17-4 43 psi (297 kPa) 0.74 SG @ 60°F (15°C)
