Veeder-Root Red Jacket Quick-Set User Manual

Parts Lists Die Spring Kit Parts
55
Figure 50. UMP Wire Termination And Sealing Kit
Die Spring Kit Parts
Table 16 lists the 410485-001 Die Spring Kit parts list.
Figure 51. Die Spring Kit
Table 16. 410485-001 Die Spring Kit Parts List
Item
(ref. Figure 51) Part No. Description Qty.
1 410133-001 Die spring 2
1
2
3
1
2X
