POS App Guide DIM Descriptions
6
- R2 - 331076-002 - RS-422 four wire
- R3 - 331076-003 - DIM RS-485 two wire (install in TLS-350R only)
- R4 - 331076-004 - DIM RS-422 four wire (install in TLS-350R only)
International Forecourt Standards Forum Dispenser Interface Module (IFSF) - TLS-
350R, TLS-450PLUS
• Required for TLS consoles that are connected to IFSF networks.
• Uses Echelon 2-wire FTT10-A medium, as defined by the IFSF standards.
• There are 3 LEDs on this board:
- Green LED On when IFSF board is transmitting information to the TLS.
- Red LED On when TLS is transmitting information to the IFSF board.
- Amber LED Off indicates normal state of the IFSF board processor.
• There are no LED indicators for network communication.
TCP/IP DIM Module (TDIM) - TLS-350R
• Installs in a communication port of the TLS-350R to communicate with or monitor the Wayne IDPOS dispenser.
• Minimum system requirements for TDIM Module operation:
- Console system software: Version 15 or higher - Version 21 or higher is recommended
- Network connection to a PC requires a hub. Connecting to a hub requires a straight CAT 5 cable
- Direct connection to a PC requires an Ethernet crossover cable
- Connection to a LAN or WAN
• There are 2 LEDs on the PC board of this module:
- Green LED indicates that the TDIM module is transmitting information to the TLS.
- Red LED indicates the TLS is transmitting information to the TDIM module.
• There is no communication alarm for this module.
TCP/IP DIM (TDIM) - TLS-450/TLS-450PLUS
• Installs in a communication port of the TLS-450/TLS-450PLUS to communicate with or monitor the Wayne
IDPOS dispenser.
• Minimum system requirements for TDIM module operation:
- Console system software: Version 4H or higher
- Network connection to a PC requires a hub. Connecting to a hub requires a straight CAT 5 cable
- Direct connection to a PC requires an Ethernet crossover cable
- Connection to a LAN or WAN
• There is no communication alarm for this module.
• TLS-450 and TLS-450PLUS hardware is standard equipment.
• TLS-450 requires BIR to activate DIM.
