POS App Guide Introduction
2
Reconciliation reports will be generated for the manifolded set as a single product. Individual adjusted delivery
reports will be provided followed by an adjusted manifolded delivery report.
Both Version 310 software (or later), and a Memory Expansion Module are required to perform BIR for manifolded
tanks.
TLS-350R System Requirements for BIR and ISD
BUSINESS INVENTORY RECONCILIATION
• TLS-350R with BIR option
• A Mag 1 (0.1 gph) magnetostrictive (standard or Mag Plus) probe is required for each tank that will be
monitored and reconciled. The Mag 1 probe for alternative fuels is also supported.
• ECPU board with the following software versions;
- w/106 [or later] software for BIR,
- w/311 [or later] software and a Memory Expansion Module for BIR with manifolded tanks, or
- w/116 or 316 [or later] software for BIR with variance analysis
• Dispenser Interface Module
For electronic dispensers, one DIM is required for each TLS-350R. Up to 3 DIMs can be installed to support
sites with multiple POS systems. For mechanical dispensers, the TLS-350R can support up to 8 mechanical
DIMs. Each mechanical DIM supports up to 4 mechanical dispensers.
One installation kit may be required for each DIM (ref. Table , “,” on page 7). The installation kits vary for each
DIM and include all required adapter boxes and cables.
IN-STATION DIAGNOSTICS
• TLS-350R with ISD option
• ECPU2 board with 325 or later software and a NVMEM203 board.
• A Mag 1 (0.1 gph) magnetostrictive (standard or Mag Plus) probe is required for each gasoline tank. The Mag 1
probe for alternative fuels is also supported.
• Dispenser Interface Module - For electronic dispensers, one DIM is required for each TLS-350R. Up to 3 DIMs
can be installed to support sites with multiple POS systems. For mechanical dispensers, the TLS-350R can
support up to 8 mechanical DIMs. Each mechanical DIM supports up to 4 mechanical dispensers.
• DIM installation kit - One installation kit may be required for each DIM (ref. Table , “,” on page 7). The installation
kits vary for each DIM and include all required adapter boxes and cables.
• Additional ISD monitoring equipment as defined by the site’s requirements, e.g., dispenser mounted Air Flow
Meters and Pressure Sensor, console Smart Sensor Modules, etc. - refer to appropriate ISD Installation Manual
for specifics.
TLS-450/TLS-450PLUS BIR Capabilities
• Support for up to 72 fueling positions
• Support for up to 6 meters (hoses) per fueling position
• Support for manifolded tanks
• Support for blending dispensers that separately meter each product prior to blending. Gilbarco, Tokheim, and
Wayne electronic blending dispensers are supported. Dispensers that blend fuel prior to the metering process,
