POS App Guide DIM Installation Examples
23
Gilbarco G-Site™ POS Systems
TLS CONSOLE SOFTWARE REQUIREMENTS
TLS-350R with BIR Software Requirements
• System software Version 17 (or higher)
• DIM software 349634-003C (or later)
TLS-450/TLS-450PLUS with BIR Software Requirements
• TLS-450 System software Version 2.x (or higher)
• TLS-450PLUS System software Version 6.x (or higher)
• BIR option required (TLS-450)
VEEDER-ROOT HARDWARE REQUIREMENTS (REF. TABLE 2)
The following equipment is required to interface the TLS to the G-Site POS:
• One Gilbarco Interface Module
• One installation kit for each current loop
SPECIFIC LIMITATIONS
Up to 36 Gilbarco Uni-Hose/MPD fueling positions are supported by the TLS-350R, and up to 72 fueling
positions are supported by the TLS-450/TLS-450PLUS.
In-dispenser credit card readers (CRINDS) are supported.
To support a DIM and the TLS-350R, the G-Site must be upgraded to include EMC interface capability. This has
been released in the following G-Site versions (EMC Interface capability will be released into the Generic G-Site
version 6):
• Exxon - version 25.0.243
• Shell - version 33.1.23
•Chevron Canada - version 8.1.10
The 331063-xxx installation kit contains two gender mender adapters. One gender mender is used for PC G-SITE
applications while both are used for C-2 G-SITEs
. The gender mender adapters are not identical. As shown in
Figure 6, be sure to use the correct part at the connection points for your particular installation.
WIRING DIAGRAM
G-Site wiring examples are shown in Figure 6 below:
