POS App Guide DIM Installation Examples
18
Gilbarco TCRG, TCRG2, T-11, and T-12 POS Systems
TLS CONSOLE SOFTWARE REQUIREMENTS
TLS-350R with BIR Software Requirements
• System software Version 17 (or higher)
• Peripheral controller software 002B (or later)
• DIM software 349634-003C (or later)
TLS-450/TLS-450PLUS with BIR Software Requirements
• TLS-450 System software Version 2.x (or higher)
• TLS-450PLUS System software Version 6.x (or higher)
• BIR option required (TLS-450)
VEEDER-ROOT HARDWARE REQUIREMENTS (REF. TABLE 2)
The following equipment is required to interface the TLS to the Transac POS:
• One Gilbarco Current Loop Dispenser Interface Module for up to 3 current loops
• One Gilbarco dispenser distribution box PA0133000
• One Gilbarco Transac DIM installation kit required per current loop. Up to 16 fueling positions are supported
per current loop.
The following POS consoles are supported:
• Transac-1e1 (PA0132, PA0141)
• Transac-12 (PA0134, PA0142)
• Transac-12A (PA0151, PA0152)
• Transac-12B (PA0173)
• Transac-12C (PA0188)
• Transac-12G (PA0203)
• TCRG (PA0180-121)
• TCRG2 (PA0180-121)
• Excentus Reward Fuel Controller
TM
, Gilbarco Dispenser Interface, V1.0.160
SPECIFIC LIMITATIONS
Only Gilbarco electronic dispensers are supported. Also, dispensers that feature a blender and a single-product
dispenser at one fueling position are not supported.
In-Dispenser credit card readers (CRINDS) or G-Site systems are not supported by the Gilbarco CDIM.
Other POS systems that use Gilbarco dispensers and the Gilbarco Pump Access Module (PAM) may also be
supported - contact Veeder-Root for assistance.
Special Note on T-11/T-12 Pre-Pay Applications
In T-11/T-12 Pre-Pay applications, cashiers should be urged to close out each transaction promptly. Failure to
close-out promptly can cause the TLS-350R to delay reconciliation reports, and impact the system’s ability to
maximize tank calibration.
