POS App Guide DIM Installation Examples
40
GasBoy CFN Systems
TLS CONSOLE SOFTWARE REQUIREMENTS
TLS-350R with BIR Software Requirements
• System software Version 17 (or higher)
VEEDER-ROOT HARDWARE REQUIREMENTS (REF. TABLE 2)
The following equipment is required to interface the TLS to the Gasboy CFN system:
• One Gasboy Dispenser Interface Module
• One installation kit
GASBOY SYSTEM REQUIREMENTS FOR BIR INTERFACE
• Console must be Site Controller II, version 2.0 or later and have “Send All Messages” feature.
• GasBoy junction box (P/N C05020).
• All Profit Point Broadcast messaging enabled.
• Non-blended dispensers (not a restriction for ISD only applications).
CONNECTING TO THE SITE CONTROLLER II
The TLS-350R must be connected to the Console Loop of the Site Controller II to receive BIR data from the CFN
(see
Figure 23).
