POS App Guide DIM Installation Examples
16
Bennett POS System
The information collected via the interface allows TLS-350R business inventory reconciliation to compare tank
totals to fuel transactions for end of day, end of shift, or end of month, running variances.
VEEDER-ROOT SOFTWARE REQUIREMENTS
• System software Version 17 (or higher)
• Peripheral controller software 330269-00B (or later)
• DIM software 349780-001A (or later)
VEEDER-ROOT HARDWARE REQUIREMENTS (REF. TABLE 2)
The following equipment is required to interface the TLS to the Bennett POS system:
• One Bennett Current Loop Dispenser Interface Module for up to 6 fueling positions
• One installation kit (for every 2 current loops (up to 12 fueling positions)
BENNETT SYSTEM LIMITATIONS
TLS-350R with BIR and TLS-350R with BIR and ISD
• Only non-blending, type 92D dispensers with Orpak controllers are supported.
TLS-350R with ISD
• All type 92D dispensers with Orpak controllers are supported.
INSTALLATION NOTES
The interface to Bennett dispensing equipment requires one CAB per dispenser current loop (for up to 6 fueling
positions) and one Bennett DIM installation kit for every 2 current loops. Typically one or two loops are required for
a single dispenser having two fueling positions. For this reason the interface kit includes two CABs with
supportivecabling. Supportive cabling required is sold in lengths, which are identified in the last three digits of the
kit form number. The length requirement is determined by the distance between the components.
Figure 2 is an example Bennett dispenser connection diagram. Each CAB has a three position input and a RJ-45
cable output to a dispenser loop. Use the “PUMP COMM” input side and the RJ-45 cable output.
