POS App Guide DIM Installation Examples
44
Figure 25. Wiring Diagram Of TLS-450/TLS-450PLUS MDIM Using Two 1871/7697 Series Pulse Transmitters & Required Barriers
115 Vac Line (Black)
Neutral (White)
401-1.eps
Barrier
P/N: 7859
Barrier
P/N: 7859
769780-012
Pulse
Transmitter
769780-012
Pulse
Transmitter
Blue
Black
Orange
Orange
Blue
Black
Orange/
Blue
Orange/
Blue
Orange
White
120
Vdc
120
Vdc
White
Orange
Note: Barriers may come
with a 2 position connector.
MDIM
MECHANICAL DISPENSER INTERFACE MODULE
L1
N
NC
NC
P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
P11
P12
120 VAC
INPUT RATING
120 VAC MAX
0 15 AMP MAX
Not used
