Veeder-Root TLS-350R PLUS - Component Dimensions; Figure 5. Wireless Component Dimensions

Example Drawings Component Dimensions
14
Component Dimensions
Dimensions of the TLS XL-Transmitter and battery housing are shown in Figure 5.
Figure 5. Wireless component dimensions
LEGEND FOR NUMBERED BOXES IN Figure 5
1. TLS XL-Transmitter dimensions 2. Battery housing dimensions
972-6.eps
1
2
.513
(13.03 mm)
W2
3.22
(81.79 mm)
3.52
(89.41 mm)
3.25
(82.55 mm)
3.81
(96.77 mm)
1.97
(50.03 mm)
10.51
(266.9 mm)
3.52
(89.41 mm)
3.22
(81.79 mm)
