Veeder-Root TLS-350R PLUS - Figure 18. Alarm Limit Settings

TLS Console Setup for MAG-XL Flex Probe TLS Limit Calculations
29
Figure 18. Alarm Limit Settings
LEGEND FOR NUMBERED BOXES IN Figure 18
1. Probe’s null zone
2. Full or Max Volume Limit - 100% (to top of tank or to beginning
of probe’s null zone as applicable)
3. High Product limit - 95% of full volume
4. Overfill limit - 90% of full volume
5. Delivery limit - 20% of full volume
6. Low Product Limit - 10% of full volume
7. Bottom of discharge port
8. Minimum volume (distance from tank bottom to bottom of dis-
charge port multiplied by tank’s gallon per inch value)
9. Concrete tank pad
972-15.eps
9
8
2
1
3
4
6
7
100%
95%
90%
10%
5
20%
