MAG-XL Flex Probe Installation Assemble the MAG-XL Flex Probe Components
18
• Stainless steel weight which holds the probe straight (item 3)
4. Get the stainless steel pin from the kit (item 4 in the above figure). Lift up the stainless steel weight (and other
components) and push the pin through the hole in the bottom end of the probe tube leaving equal lengths of
the pin on each side of the tube (this will secure the above components on the probe’s tube).
PROBE INSTALLATION - TOP OF TANK 2-INCH PIPE FITTING
1. Cut ONLY the tie wrap at the bottom end of the probe’s tube (the end with a hole through the tube) - not the
end with the two wires coming out of the threaded plug. Leave the other tie wraps intact. This will prevent the
coil from unwrapping before installation.
2. Get the Optional 2-inch Adapter/Reducer (2” to 3/4”) kit.
3. Slide the components (see Figure 9) onto the bottom end of the tube in the following order:
• 2” to 3/4” Adapter/Reducer (item 1)
• Product Float (item 2)
• Stainless steel weight which holds the probe straight (item 3)
4. Get the stainless steel pin from the probe kit (item 4 in the above figure). Lift up the stainless steel weight (and
other components) and push the pin through the hole in the bottom end of the probe tube leaving equal
lengths of the pin on each side of the tube (this will secure the above components on the probe’s tube).
Figure 9. MAG-XL Flex Probe components - manway install
Figure 10. MAG-XL Flex Probe components - pipe fitting install
