MAG-XL Flex Probe Installation Installing the TLS XL-Transmitter
22
Figure 13. Installing TLS XL-Transmitter - manway riser pipe
LEGEND FOR NUMBERED BOXES IN Figure 13
1. Battery pack
2. 4” brass riser cap
3. Single-gang box from BELL outdoor, P/N 5321-0, or equivalent
(customer supplied)
4. 1/2” galvanized nipple
5. 1/2” brass hex adapter
6. TLS XL-Transmitter
7. 3/4” x 1/2” NPT reducing bushing (customer supplied)
8. 3/4” NPT probe threaded fitting
9. 4” riser, recommended riser length of 10”, actual length depen-
dent on probe insertion length (customer supplied)
6
3
4
1
2
7
972-4.eps
8
5
9
CAUTION! TIGHTEN
CORD GRIPS TO PREVENT
WATER INGRESS!
