Veeder-Root TLS-350R PLUS - Example MAG-XL Flex Probe Installation in Existing Tank Opening; Figure 4. MAG-XL Flex Probe Installation Without Riser Pipe, Top Mounted in Existing Tank Opening

Example Drawings Example MAG-XL Flex Probe Installation in Existing Tank Opening
13
Example MAG-XL Flex Probe Installation in Existing Tank Opening
Figure 4. MAG-XL Flex Probe installation without riser pipe, top mounted in existing tank opening
LEGEND FOR NUMBERED BOXES IN Figure 3
1. Pipe cap with 3/4” NPT threaded opening (customer supplied)
2. Weatherproof junction box with 3/4” to 1/2” reducing bushing
in top opening (customer supplied)
3. Battery pack
4. 1/2” conduit, 6” minimum length, threaded both ends (cus-
tomer supplied)
5. 1/2” NPT Brass adapter
6. TLS XL-Transmitter
7. Battery cable
8. MAG-XL Flex Probe Weight set a minimum distance above bot-
tom of tank (see Table 1).
9. Tank grounding (ref items 8 - 11 in Figure 2).
972-2c.eps
8
4
5
6
2
1
3
7
9
