TLS Console Setup for MAG-XL Flex Probe Height Reading Adjustment
27
Figure 17. In-tank setup for TLS Consoles used with MAG-XL Flex Probes
972-14.eps
TLS Console Setup
Example of In-Tank Setup for MAG-XL Flex Probes used with TLS Consoles
Parameter
Value Notes
PRODUCT LABEL T1: Fuel Oil Customer to specify product name
PRODUCT CODE: 1 Code used by the point-of-sale terminal
THERMAL COEFF: 0.00047 Coefficient value depends on product type
TANK DIAMETER: 432
Enter the internal tank height not diameter
1
TANK PROFILE:
LINEAR
2
Setting for Vertical Tanks
FULL VOLUME: 115,925
Ex: 115,925 gallon tank capacity
1
METER DATA PRESENT: NO Not Used for MAG-XL Flex Probe Setup
CAL UPDATE: IMMEDIATE Leave at the default setting
FLOAT SIZE: 4.0 IN. Always set to 4" for MAG-XL Flex Probes
WATER WARNING: 2.0 Not Used for MAG-XL Flex Probe Setup
HIGH WATER LIMIT: 4.0 Not Used for MAG-XL Flex Probe Setup
MAX or LABEL VOL: 110,000 Maximum safe working volume
OVERFILL LIMIT: 90% Maximum volume warning during a delivery
HIGH PRODUCT: 95% Maximum volume alarm setting
DELIVERY LIMIT: 20%
10%
Low tank volume warning
LOW PRODUCT: Set to a level higher than the discharge port
LEAK ALARM LIMIT: 0 Not Used for MAG-XL Flex Probe Setup
SUDDEN LOSS LIMIT: 0 Not Used for MAG-XL Flex Probe Setup
TANK TILT:
0
2
Not Used for Mag-XL Probe Setup
PROBE OFFSET:
4
2
Distance between probe and tank bottom
1
T1: SIPHON MANIFOLDED 0 Not Used for MAG-XL Flex Probe Setup
T1: LINE MANIFOLDED 0 Not Used for MAG-XL Flex Probe Setup
Multiple Leak Testing Parameters Not Used Not Used for MAG-XL Flex Probe Setup
DELIVERY DELAY: 01 Delay time in minutes (up to 99)
PUMP THRESHOLD: Not Used Not Used for MAG-XL Flex Probe Setup
Press STEP to set additional tanks Repeat above in-tank setup for each probe
Values shown above are for reference only
1
For further details on how to calculate this value, reference the appropriate
explanations included in this manual.
2
Setting this value correctly is critical to product performance.
See TLS Limit Calculations on next page.
3
3
3
3
3
3
