Veeder-Root TLS-350R PLUS - Figure 15. Connecting Input Wiring to Transmitter Terminal Blocks; Figure 16. Connecting Probe and Battery Pack Cables to the TLS XL-Transmitter

MAG-XL Flex Probe Installation Connecting MAG-XL Flex Probe Wiring
24
Figure 15. Connecting input wiring to transmitter terminal blocks
Figure 16. Connecting probe and battery pack cables to the TLS XL-Transmitter
LEGEND FOR NUMBERED BOXES IN Figure 15
1. Strip back cable and wire jackets the amount shown.
2. Use a screwdriver with the proper blade width.
3. Wires must be tight in terminals!
LEGEND FOR NUMBERED BOXES IN Figure 16
1. MAG-XL Flex Probe cable connections:
•Red to P (power)
•White to D (data)
•Black to G (ground)
2. S1 DIP switch
3. S2 DIP switch
4. Battery power cable connections -– observe polarity:
• +IN (White)
•–IN (Black)
5. Red Battery ID label attached to both ends of battery cable
Pay close attention to the polarity of the battery input
connections. Reversing the connections can cause dam-
age to the TLS RF.
964-23.eps
1/4"
1-1/4"
1
3/32" (2.4mm)
2 3
972-5.eps
5
Battery
Connection
CAUTION! TIGHTEN
HEX ADAPTER AND
CORD GRIP TO PREVENT
WATER INGRESS!
2
1
3
4
S1
S2
+IN
-IN
BATTERY
PROBE
PDG
