MAG-XL Flex Probe Installation Assemble the MAG-XL Flex Probe Components
17
• DO NOT ASSEMBLE THE WEIGHT AND FLOATS ON THE MAG-XL Flex Probe UNTIL READY TO BE
INSTALLED IN THE RISER. Carry the parts to the top of the tank before assembling. Do not unwrap the MAG-
XL Flex Probe until ready to install.
• DO NOT TWIST THE MAG-XL Flex Probe DURING INSTALLATION. Always keep the coils of the MAG-XL Flex
Probe parallel as you “unroll” it into the tank.
• DO NOT LET THE COIL BECOME LESS THAN 44.50” IN DIAMETER WHILE UNCOILING.
Assemble the MAG-XL Flex Probe Components
CAUTION! the following procedures are conducted on top of the tank. Observe all safety
precautions for working on tall and possibly slippery structures.
PROBE INSTALLATION - MANWAY 4-INCH RISER PIPE
1. Cut ONLY the tie wrap at the bottom end of the probe’s tube (the end with a hole through the tube) - not the
end with the two wires coming out of the threaded plug. Leave the other tie wraps intact. This will prevent the
coil from unwrapping before installation.
2. Get the optional 4-inch Riser Cap installation kit.
3. Slide the components (see Figure 9) onto the bottom end of the tube in the following order:
• 4-inch riser cap (insert end of probe through the 3/4” tapped hole in the riser cap) (item 1)
• Product Float (item 2)
Figure 7. Do not bend top 2 feet of probe Figure 8. Do not twist one coil 90° from the others
