Introduction Precautions Against Static Electricity
3
Precautions Against Static Electricity
Before removing electronic components from their antistatic bags read the following static electricity precautions.
1. Before handling any components, discharge your body's static electric charge by touching a grounded
surface.
2. Do not remove parts from their antistatic bags until you are ready to install them.
3. Do not lay parts on the antistatic bags! Only the insides are antistatic.
4. When handling parts, hold them by their edges and their metal mounting brackets.
5. Avoid touching components or edge connectors that plug into slots and wear the antistatic wrist strap (Part
No. 576010-908) included in your component replacement kit.
6. Never slide parts over any surface.
7. Avoid plastic, vinyl, and styrofoam in your work area.
System Backup
Before powering off the console perform a system backup:
WARNING! For all software maintenance functions in consoles you must use the CPU USB printer
port.
PERFORM THE FOLLOWING STEPS.
1. Turn off power to the console.
2. Using a T-15 Torx driver, remove the two screws in the left door of the console (ref. item 2 in Figure 6).
3. Disconnect the Printer's USB cable from its connector on the CPU board and insert your V-R Backup thumb
drive (P/N 330020-607) into the CPU USB connector as shown in Figure 1 below.
4. Close the door. Turn on power to the console.
