Use an electrical switching valve, such as the Festo CPE, in the pneumatic line
.
With this valve, you can switch off the air supply.
Optionally you can install an additional hand-operated switching valve, such as
the Festo VHEM in the pneumatic line. In emergencies you can then interrupt the
pneumatic air supply on site and switch off the source
holder. Mount this hand-
operated switching valve in a safe position outside the radiated area.
The pneumatic actuation can be operated as follows:
1. Remove the padlock
2. Pull out the locking bolt.
These steps secure the "OFF" position
.
The locking bolt is fixed on a steel cable.
3. Using compressed air, switch the pneumatic actuator from the "OFF"
position to the "ON" position. The pneumatic actuator should move without
interruption to the "ON" position.
Do not grasp any mechanical parts of the pneumatic drive while the
pneumatic actuator is switching over.
Insert the unused locking bolt into its parked position.
Apart from the safety hole, there is another laterally displace hole in
which you can insert the locking bolt for safe retention.
Attach the required padlock to the locking bolt so that the padlock
does not get lost.
!
CAUTION
