7 Setup
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
tablets with iOS or Android operating system or PCs with PACTware
and Bluetooth USB adapter.
The following functional descriptions apply to all adjustment devices
(smartphone, tablet, laptop …).
For technical reasons, individual functions are not available on all
devices.Youcanndinformationonthisinthefunctiondescription.
The adjustment menu is divided into three sections:
Main menu: Measurement loop name, application etc.
Extended functions: Output, switching output, display, reset etc.
Diagnosis: Status, pointer function, simulation, sensor information
etc.
Note:
Please note that individual menu items are only optionally available or
depend on the settings in other menu items.
Menu item Function Default value
Measurement loop name Free naming of the device Sensor
Application Selection of the application Standard
Adjustment with medium
5)
Media adjustment Accept current device status
Menu item Function Default value
Output Transistor function PNP
Function output (OU1) Opener (HNC)
Switching output Switching point (SP1) 67 %
Switching delay (DS1) 0.5 s
Reset point (RP1) 65 %
Reset delay (DR1) 0.5 s
Indication Brightness LED illuminated ring 100 %
Signalling NAMUR NE 107
Fault Red
Switching output Yellow
Operating status Green
Access protection Bluetooth access code See supplementary sheet "PINs and
Codes".
Protection of the parameterization Deactivated
Reset - -
Units Temperature unit °C
General information
Main menu
Extended functions
5)
 Onlyfor"User-dened"application
