3 Product description
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
3 Product description
3.1 Conguration
The scope of delivery encompasses:
•
VEGAPOINT 21 point level switch
•
Information sheet " Documents and software" with:
– Instrument serial number
– QR code with link for direct scanning
•
Information sheet " PINs and Codes" (with Bluetooth versions)
with:
– Bluetooth access code
Note:
Optional instrument features are also described in this operating
instructions manual. The respective scope of delivery results from the
orderspecication.
This operating instructions manual applies to the following instrument
versions:
•
Hardware version from 1.0.0
•
Software version from 1.3.0
The VEGAPOINT 21 consists of the components:
•
Housing with integrated electronics
•
Processtting
•
Plug
1
2
3
4
5
Fig. 1: VEGAPOINT 21
1 LED illuminated ring
2 Instrument housing
3 Processtting
4 Sensor
5 Plug connection
Youwillndthetypeplateonthesensorhousing.
Scope of delivery
Scope of this operating
instructions
Constituent parts
Type label
