13 Supplement
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
13 Supplement
13.1 Technical data
Note for approved instruments
The technical data in the respective safety instructions which are included in delivery are valid for
approvedinstruments(e.g.withExapproval).Thesedatacandierfromthedatalistedherein,for
example regarding the process conditions or the voltage supply.
All approval documents can be downloaded from our homepage.
Materials and weights
Material 316L corresponds to 1.4404 or 1.4435
Materials, wetted parts
Ʋ Sensor tip PEEK, polished
Ʋ Device seal - Standard version FKM
Ʋ Device seal - Hygienic version EPDM
Ʋ Process seal Klingersil C-4400
Ʋ Processttings 316L
Materials, non-wetted parts
Ʋ Housing 316L and plastic (Valox and polycarbonate)
Ʋ Device seal - Hygienic design AC and
AM
7)
EPDM
Ʋ Seal plug NBR
Weight approx. 250 g (0.55 lbs)
General data
Processttings
Ʋ Pipe thread, cylindrical (DIN 3852-A) G½, G¾, G1
Ʋ Pipe thread, conical (ASME B1.20.1) ½ NPT, ¾ NPT, 1 NPT
Ʋ Metricnethread,cylindrical M 24 x 1.5
Threaded and hygienic adapter
Ʋ Standard hygienic adapter G½, G1
Ʋ Clamp 1", 1½", 2"
Ʋ Collar socket DIN 11851, PN40 DN 25, DN 32, DN 40
Max.torque-processtting
Ʋ Thread G½, ½ NPT 50 Nm (37 lbf ft)
Ʋ Thread G¾, ¾ NPT 75 Nm (55 lbf ft)
Ʋ Thread G1, 1 NPT 100 Nm (73 lbf ft)
Ʋ Hygienic adapter 20 Nm (15 lbf ft)
Surface quality R
a
< 0.76 µm (3.00
-5
in)
Measurement accuracy
Hysteresis approx. 1 mm (0.04 in)
7)
not in contact with the medium
