13 Supplement
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
VEGAPOINT 21, hygienic version - Thread
ø 30 mm
(1.18")
ø 50,5 mm
(1.99")
47,5 mm
(1.87")
ø 18 mm
(0.71")
G
1
/
2
149 mm
(5.87")
ø 36 mm
(1.42")
12,5 mm
(0.49")
149 mm
(5.87")
SW 21/32
1 2
SW 21/32
ø 36 mm
(1.42")
35 mm
(1.38")
ø 27 mm
(1.06")
36 mm
(1.42")
35 mm
(1.38")
ø 27 mm
(1.06")
36 mm
(1.42")
Fig. 21: VEGAPOINT 21, hygienic version - thread, with ISO 4400 plug
1 Thread G½ for hygienic threaded adapter (DIN ISO 228/1) with ISO 4400 plug connection
2 VEGAPOINT 21, hygienic version in threaded adapter, Clamp
