Veichi SI10 - Page 23

Solar Pump Controller Manual
22
E-05
Frequency give
channels
combinations
mode
0:Main channel valid
1:Auxiliary channel valid
2:Main+auxiliary
3:Main+(K×auxiliary)
4:Main-(K×auxiliary)
5:MAX[main,(K×auxiliary]
6:MIN[main,(K×auxiliary]
7:Auxiliary +(K×main)
8: Auxiliary -(K×main)
9:MAX[(K×main), auxiliary]
10:MAX[(K×main), auxiliary]
0
〇
105H
E-06
Upper LED
display content
0:Frequency
reference
1:Output frequency
2:Output current
3:Input voltage
4:Output voltage
5:Machine speed
6: PID reference value
7: PID feedback value
0
●
106H
E-07
Lower LED
display content
1
●
107H
E-08
REV/JOG
selections
0:REV
1:JOG
0
●
108H
E-09 MAX frequency
0.50～400.0Hz
50.0
〇
109H
E-10 Upper limitation
Lowest limitation～MAX
fre
q
uenc
y
50.00
●
10AH
E-11
Lowest
limitation
0.00～upper limitation
0.00
●
10BH
E-12
Lowest
limitation
run mode
0:Stop
1:Run as lowest limitation
1
●
10CH
E-13 ACC time 1
0.1～6500.0s
※
●
10DH
E-14 DEC time 1
0.1～6500.0s
※
●
10EH
E-15
A
CC,DEC
mode
0:Beeline
1:S curve
0
●
10FH
E-16
Keyboard
number set
frequency
Lowest limitation～upper
limitation
50.00
●
110H
E-17
V/F curve
selection
0: Constant torque curve
1: 1.5 power falling torque curve 1
2: 1.7 power falling torque curve 2
3: 2.0 power falling torque curve 3
4:User-defined curve
0
〇
111H
E-18 Torque improve
0.0%:automatic
0.1%～25.0%
※
●
112H
E-19
Output phase
limit coefficient
0～600.0
5.0
●
113H
