Veichi SI10 - Special functions parameter

Solar Pump Controller Manual
32
F-67
Keyboard
potentiometer input
voltage lower limit
0.00V～[F-68]
0.20
●
243H
F-68
Keyboard
potentiometer input
voltage upper limit
[F-67] ～5.50V
4.8
●
244H
F-69
Keyboard
potentiometer gain
0.50～5.00
1.00
●
245H
F-70
Ascend/descend
terminal preset
frequency
0.00Hz～frequency upper limit
0.00
●
246H
F-71 Reserve
247H
★ Special functions parameter
NO. Function description
Range of settings and definition
Factory setting
Belonging
Communication
address
H-01
Free-setting voltage
V1
0.0%～[H-03] 3.0
〇
301H
H-02
Free-setting
frequency F1
0.0Hz～[H-04] 1.00
〇
302H
H-03
Free-setting voltage
V2
[H-01～H-05] 28.0
〇
303H
H-04
Free-setting
frequency F2
[H-02～H-06]
10.00
〇
304H
H-05
Free-setting voltage
V3
[H-03～H-07] 55.0
〇
305H
H-06
Free-setting
frequency F3
[H-04～H-08]
25.00
〇
306H
H-07
Free-setting voltage
V4
[H-05～H-09]
80.0
〇
307H
H-08
Free-setting
frequency F4
[H-06～H-10]
37.50
〇
308H
H-09
Free-setting voltage
V5
[H-07] ～100.0%
100.0
〇
309H
H-10
Free-setting
frequency F5
[H-08] ～maximum frequency
50.00
〇
30AH
H-11
PID output
characteristic
0:Positive characteristic
1:Negative characteristic
0
〇
30BH
