Solar Pump Controller Manual
40
H-64
CVT adjust voltage bias
limitation
Range：0～10.0% Factory setting：0.0%
These parameters make bus voltage keep between H-62*(H-63 - H-64) and H-62*(H-63 + H-64) at
CVT mode
H-65
Dry run protection limit current
Range：0～1000.0A Factory setting：0.0A
While it valid, F-22 enters to dry run protection state if C-03 current bigger than H-65 limit current
and judge if dry protection again after F-23 time.
Note: [H-32～H-65] only valid while solar pump control mode ( E-02 set to 10)
Monitorin
g code
Content Units
Communi
cation
code
C-1 Frequency reference 0.01Hz C01H
C-2 Output frequency 0.01Hz C02H
C-3 Output current 0.1A C03H
C-4 Input power 0.1KW C04H
C-5 DC Bus voltage V C05H
C-6 Bus current 0.1A C06H
C-7
PID give value or search frequency step (while E-02=10)
%
C07H
C-8
PID feedback or CVT base voltage(while E-02=10) %
C08H
C-9 Module temperature ℃ C09H
C-10
Accumulative operation time (accumulate while
frequency higher than 0, not time while 0speed or stop)
Hour C0AH
C-11 Running duration time Min C0BH
C-12 Bus bar current 0.1A C0CH
C-13 PID adjust frequency(minus can not show) % C0DH
C-14 Input terminals connect/disconnect status
See
below
diagram
C0EH
C-15 Input terminals connect/disconnect status
See
below
diagram
C0FH
C-16 Terminal VS1 input value 0.1V C10H
C-17 Terminal AS input value 0.1mA C11H
C-18 Terminal VS2 input value 0.1V C12H
C-19 Terminal pulse input value ※ C13H
C-20 Counter record ※ C14H
C-21 DC bus voltage V C15H
