Veichi SI10 - Chapter 4: Solar Pump Controller Parameter Table; Basic parameter

Solar Pump Controller Manual
21
Chapter 4: Solar Pump Controller Parameter Table
“●”:can revise while inverter running
“〇”:can not revise while inverter running
“×”:can only read, can not change
“–”:factory setting, can only set by factory
“
※ ”:is related to model no
★ Basic parameter
NO.
Function
description
Range of settings and definition
Factory
setting
Belonging
Communic
ation
address
E-01
Run order
reference
0:Keyboard
1:Terminal
2:Communication
(Configuring for 1 and FWD and
COM is ON, the inverter will
automatic running)
0
〇
101H
E-02
Frequency
reference
main channel
selection
0:Keyboard digital setting
1:Keyboard potentiometer
3:AS current signal,4-20mA
4:VS2 voltage signal,-10V-10V
5:Terminal pulse signal
6:RS485 communication
7: UP/DOWN control
8: Normal PID control
9:Constant voltage PID control
10: Solar pump control
11:Swing frequency run
12: Terminal switch
10
〇
102H
E-03
Frequency give
auxiliary
channel
selection
0:Keyboard number setting
1:Keyboard potentiometer
3: Terminal AS current signal,
4-20mA
4:Terminal VS2 voltage signal,
-10-10V
5:Terminal pulse signal
6:RS485 communication port
7:UP/DOWN control
8:PID control
9:Constant voltage PID control
10:Programme run
0
〇
103H
E-04
Frequency give
channel gain
0.01～5.00 1.00
〇
104H
