★ Out terminals parameter
NO.
Function
description
Range of settings and definition
Factory
setting
Belonging
Communi
cation
address
F-01
Input signal options
1(X1)
0:Invalid
1:Positive jog operation
2:Negative jog operation
3:Free stop
4:Fault reset
5:Multi-step speed contol1
6:Multi-step speed contol2
7:Multi-step speed contol3
8:Multi-step speed contol4
9:Ascend/descent running frequency
UP
10:Ascend /descent running
frequency DW
11:Trilinear operation mode control
12:PID control pause
13:Exterior fault alarm
14:Acceleration and deceleration time
selection terminal 1
15:Acceleration and deceleration time
selection terminal 2
16:Frequency setting channel
Selection terminal 1
17:Frequency setting channel
Selection terminal 2
18:Frequency setting channel
Selection terminal 3
19:Frequency setting channel
Selection terminal 4
20:Program running suspension
21:Program running restart
22:Timer trigger terminal
23:Timer reset terminal
24:Timer Auto-Nulling terminal
25:Outer clock input terminal
26:Reserve
27:Solar pump control cancel
1
〇
201H
F-02
Input signal options
2(X2)
4
〇
202H
F-03
Input signal options
3(X3)
3
〇
203H
F-04
Input signal options
4(X4)
27
〇
204H
F-05
Input signal options
5(X5)
5
〇
205H
F-06
Input signal options
6(X6)
6
〇
206H
