Veichi SI10 - Page 32

Solar Pump Controller Manual
31
F-58
Input signal
Characteristics
selection
LED 0 digit:VS1 input characteristic
selection
0:Positive characteristic
1:Negative characteristic
LED 10 digit: AS input characteristic
selection
0:Positive characteristic
1:Negative characteristic
LED 100 digit: VS2 input
Characteristic selection
0:Positive characteristic
1:Negative characteristic
LED 1000 digit: impulse input
characteristic selection
0:Positive characteristic
1:Negative characteristic
0000
●
23AH
F-59
Terminal analog
input filter time
constant
0.01～5.00 second
0.50
●
23BH
F-60
Output terminal
(AO1) selection
0:Output signal close
1:Output frequency/speed
2:Output current
3:Given frequency/speed
4:PID given quantity
5:PID feedback Quantity
6: DC bus voltage
7: Output voltage
1
●
23CH
F-61
Output terminal
(AO2) selection
3
●
23DH
F-62
(AO2) output signal
selection
0: Frequency pulse output
1: 0～20mA
2: 4～20mA
3: 0～10V
3
●
23EH
F-63
(AO1) output signal
gain
25%～200%
100
●
23FH
F-64
(AO2) output signal
gain
25%～200%
100
●
240H
F-65
(AO1) output signal
zero adjustment
-10.0%～10.0%
0.0
●
241H
F-66
(AO2) output signal
Zero adjustment
-10.0%～10.0%
0.0
●
242H
