HP25E / HP30E 6. Graphical control
6-35© VEMAG 2018
6.6.4.11 Synchronizing the machine using an external signal
Display: Portions per signals
Selection: O / Number
Unit: Number
Resolution: 1
Setting range: 1 – 999,999
Application: Continuous mode and portioning controlled by machine
downstream (optional)
• Enter number of portions and number of signals.
• Press Enter.
“Signal processing” opens a window with the corresponding values for
diagnostic purposes.
6.6.4.12 Linking support
Display: Linking support
Unit: Gramme [g]
Resolution: 0,1 g
Setting range: 0.0 — portion weight (0.0 = O)
Application: FSL 210, FSL 211
• Enter linking support.
• Press Enter.
This parameter can be used to set additional back suction after each por-
tion.
