C-7
Part #1169256 09/2008
CABINET ASSEMBLY
* NOTE: WHEN ORDERING CABINET ASSEMBLY, PLEASE PROVIDE 9-CODE OR 11-CODE AND
MANUFACTURER’S DATE CODE.
**NOTE: WHEN ORDERING DECALS, PLEASE PROVIDE STYLE.
ITEM NO DESCRIPTION QTY REQ PART NO.
1* CABINET ASSEMBLY - FOAMED 1 ~
2 HINGE PIN 1 389071
3 RAMP 1 1120387
4 LEVELING LEG 1 1059902
5 CONDENSATE PAN 1 1122475
6 DRAIN TUBE 1 1088449-1
7 FIBERGLASS EVAPORATOR BOARD 1 1122728
8 DRAIN TUBE GASKET 1 387837
9 DRAIN TUBE FUNNEL 1 1068678
10 NUT - DRAIN TUBE 1 387925
11 BRACKET - REFRIGERATION 2 1123527
12 QUICKER LOCK ASSEMBLY 1 1123724
13 LATCH BRACKET 1 1123675
14 NUT RETAINER HOUSING 1 1123689
15 NUT SEGMENT 3 1033085
16 SPRING 1 389690
17 CAP 1 1111988
18** SIDE DECAL 2 **
19 STACK SUPPORT 1 1123018
20 TOP HINGE 1 2000805-03
21 BRACKET STACK SUPPORT 2 1079007
22
AIR DAM/KICK PANEL ASSEMBLY, 39” 1 1123440
AIR DAM/KICK PANEL ASSEMBLY, 32” 1 1123440-1
23 DOOR SWITCH BRACKET 1 1121043
24 DOOR SWITCH 1 323007
25
OVERLAPPING DOOR GUARD - 72” 1 2001376
OVERLAPPING DOOR GUARD - 79” 1 2002325
26 SEAL, 39” 1 1122500
27
VEND CHUTE, 39” 1 1123453
VEND CHUTE, 32” 1 1123451
28 CHUTE BRACKET 1 1077864
29 DROP SENSOR 1 1122923
30 DROP SENSOR MOUNTING BRACKET 1 1123601
31 FOAM PAD, DROP SENSOR 2 1123654
32
SAFETY SCREEN, 39” 1 1128567
SAFETY SCREEN, 32” 1 1128775
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-16
