C-13
Part #1169256 09/2008
REFRIGERATION ASSEMBLY
ITEM
NO
DESCRIPTION QTY
REQ
PART NO.
1 REFRIGERATION ASSEMBLY D90 TE S 1/3 R134a CAP START 1 1123589
2 ORIFICE PLATE, SINGLE FAN 1 390228
3 TEMPERATURE SENSOR ASSEMBLY 1 1124254
4 TEMPERATURE SENSOR 1 1122924
5 TEMPERATURE SENSOR BRACKET 1 1124156
6 CLAMP, 1/4” 1 324099-2
7 PUSH MOUNT CLAMP 1 384692
8 EVAPORATOR FAN BLADE 1 1113562
9 FAN MOTOR - EVAPORATOR 1 42321-17
10 BRACKET - FAN MOTORS 6 1117996
11 RIGHT AIR BAFFLE - EVAPORATOR 1 1123564
12 SMALL AIR DUCT - EVAPORATOR 1 1124097
13 FOAM TAPE, 3.5” 1 1124421-2
14 EVAPORATOR EXTENSION BRACKET 1 1124158
15 FOAM TAPE, 32.5” 1 1124421
16 CONDENSER DUCT 1 1122413
17 FAN MOTOR - CONDENSER, 115V 1 1121770
18 FAN MOTOR CLIP - CONDENSER 1 V42323
19 BASE - REFRIGERATION 1 1122470
20 START RELAY (PART OF ASSY 513506066) 1 --
21 OVERLOAD PROTECTOR (PART OF ASSY 513506066) 1 --
22 COVER - OVERLOAD (PART OF ASSY 513506066) 1 --
23 CLIP - COMPRESSOR MOUNT 2 343874
24 STUD - COMPRESSOR MOUNT 2 390102
25 CLAMP, 5/16” 1 324099-3
26 CAPACITOR ASSEMBLY 1 1112805
27 BRACKET - CAPACITOR 1 1112848
28 CAPACITOR-START/END 1 1122999
29 CAPACITOR CLIP 1 1076481
30 EDGE TRIM - SHORT 3 388304-1
31 EDGE TRIM - LONG 1 388304-3
32 COMPRESSOR POWER HARNESS 1 1121019-1
33 EVAPORATOR FAN HARNESS 1 1122193
34 EVAPORATOR POWER HARNESS 1 1124185
35 EVAPORATOR 1 1122235
36 EVAPORATOR COVER 1 1124099
37 CONDENSER FAN BLADE 1 389614
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-16
