C-16
Part #1169256 09/2008
SandenVendo America, Inc. HARNESS QUICK REFERENCE GUIDE
TRADE VENDORS
PART NO. DESCRIPTION PURPOSE 721 821 621
1122905 Door Harness Connects motors, temp. sensors, transformer, drop
sensors, and relays to the contol board
XXX
1111287 Selection Harness - 10 select
Connects the selection buttons to the control board
X X N/A
1117872 Selection Harness - 8 select
Connects the selection buttons to the control board
N/A N/A X
1111252 Display Harness Connects the display to the control board X X X
1122918 Motor Harness - 10 select Connects the vend motors to the door harness X X N/A
1123050 Motor Harness - 8 select Connects the vend motors to the door harness N/A N/A X
1122193 Evaporator Fan Harness Connects the evaporator fans to the power
distribution box
XXX
1123444 Power Distribution Harness Input for 110v service cord and output to compressor,
evaporator, fans, control board, and transformer
XXX
1124065 Motor Harness w/ Pre-cool -
10 select
Connects the vend motors to the door harness
X X N/A
1124066 Motor Harness w/ Pre-cool -
8 select
Connects the vend motors to the door harness
N/A N/A X
1124864 Live Display Lighting Harness Connects the lights to the control board X X X
1087309 Live Display Selection Harness -
10 select
Connects the selection buttons to the control board
X N/A N/A
1124725 Live Display Selection Harness -
8 select
Connect the selection buttons to the control board
N/A N/A X
1123909 Live Display Read-to-Vend/
Soldout Harness
Connects the vend motors to the door harness
X N/A X
1124570 MDB Harness Connects the coinage to the control board X X X
